MONOBOLT®
MONOBOLT® 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts
SKU No
:
02771-00817
MONOBOLT® 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts
Product description :
2.03-9.53 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Dome Head Style with Steel Body material and Steel Mandrel material
Compare
Add to Smartlist
Talk to an Expert
Tech- Specifications
Features
Download Literature
2.032-9.525 mm Steel/Steel Monobolt Structural Blind Rivets
product name
Steel
Body Material
Brand
Steel
Mandrel Material
Zinc Plate
Finish-Body
Zinc Plate
Finish- Mandrel
Head Style
Dome
Min grip mm
2.03
Max grip mm
9.53
Min Grip Inches
0.08
Max Grip Inches
0.375
Min Hole Size mm
6.6
Max Hole Size mm
7.0
Min Holes Size Inches
0.26
Max Hole Size Inches
0.275
Max Secondary Protrusion mm
23.7
Max Secondary Protrusion inches
0.933
Flange Diameter mm
13.4
Flange Diameter inches
0.525
Flange Thickness mm
2.9
Flange Thickness Inches
0.114
Shear kN
11.78
Tensile kN
10.45
Shear lbf
2650.0
Tensile lbf
2350.0
Nominal Diameter
6.4mm [1/4]
Max Secondary Protrusion Inches
0.933
