Avibulb XT
Avibulb XT 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts
SKU No
:
0BN01-00816
Avibulb XT 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts
Product description :
1.5-5.5 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Dome Head Style with Steel Body material and Steel Mandrel material
Compare
Add to Smartlist
Talk to an Expert
Tech- Specifications
Features
Download Literature
1.5-5.5 mm Steel/Steel Avibulb XT Structural Blind Rivets
product name
6.4mm [1/4] (8)
nominal Diameter
Brand
Steel
Body Material
Steel
Mandrel Material
Zinc Plate
Finish-Body
Finish- Mandrel
Zinc Plate
Head Style
Dome
Min grip mm
1.5
Max grip mm
5.5
Min Grip Inches
0.59
Max Grip Inches
0.27
Min Hole Size mm
6.6
Max Hole Size mm
7.0
Min Holes Size Inches
0.259
Max Hole Size Inches
0.275
Max Body Length mm
13.0
Max Body Length Inches
0.512
Max Secondary Protrusion mm
17.3
Max Secondary Protrusion inches
0.6811
Flange Diameter mm
13.4
Flange Diameter inches
0.528
Flange Thickness mm
3.1
Flange Thickness Inches
0.122
Shear kN
11.1
Tensile kN
6.8
Nominal Diameter
6.4mm [1/4]
Max Secondary Protrusion Inches
0.681
Shear lbf
2495.0
Tensile lbf
1528.0
Show more Specifications
