Hemlok 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts
SKU No
:
02221-00818
Hemlok 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts
Product description :
7.5-9.5 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Dome Head Style with Steel Body material and Steel Mandrel material
Compare
Add to Smartlist
Talk to an Expert
Tech- Specifications
Features
Download Literature
7.5-9.5 mm Steel/Steel Hemlok Structural Blind Rivets
product name
6.4mm [1/4] (8)
nominal Diameter
Brand
Steel
Body Material
Steel
Mandrel Material
Zinc Plate
Finish-Body
Finish- Mandrel
Zinc Plate
Head Style
Dome
Min grip mm
7.5
Max grip mm
9.5
Min Grip Inches
0.295
Max Grip Inches
0.374
Min Hole Size mm
6.7
Max Hole Size mm
6.9
Min Holes Size Inches
0.264
Max Hole Size Inches
0.272
Max Secondary Protrusion mm
19.7
Max Secondary Protrusion inches
0.7752
Flange Diameter mm
13.4
Flange Diameter inches
0.527
Flange Thickness mm
2.7
Flange Thickness Inches
0.105
Shear kN
15.0
Tensile kN
8.8
Max Body Length mm
19.7
Max Body Length Inches
0.775
Nominal Diameter
6.4mm [1/4]
Max Secondary Protrusion Inches
0.775
Shear lbf
3372.0
Tensile lbf
1978.0
